Q7500078 As above, but for 610 mm (24 in.) pipe OD SFA1-Flexo-OD24
Q7500079 As above, but for 660 mm (26 in.) pipe OD SFA1-Flexo-OD26
Q7500080 As above, but for 711 mm (28 in.) pipe OD SFA1-Flexo-OD28
Q7500081 As above, but for 762 mm (30 in.) pipe OD SFA1-Flexo-OD30
Q7500082 As above, but for 813 mm (32 in.) pipe OD SFA1-Flexo-OD32
Q7500083 As above, but for 864 mm (34 in.) pipe OD SFA1-Flexo-OD34
Q7500084 As above, but for 914 mm (36 in.) pipe OD SFA1-Flexo-OD36
Q7500085 As above, but for 1067 mm (42 in.) pipe OD SFA1-Flexo-OD42
Q7500086 As above, but for 1219 mm (48 in.) pipe OD SFA1-Flexo-OD48
Q7500087 As above, but for flat surfaces SFA1-Flexo-Flat
Table 13 Wedges for automated inspections
Part order
number
Description Marketing number
Q7500088 Standard wedge for flexible array probe (FA1), compatible
with MapROVER and SteerROVER scanners. The wedge
is used to generate 0° Longitudinal waves and features a
curvature matching 219 mm (8.625 in.) OD for inspection
of extrados and intrados of pipe elbows. The wedge also
features a 9 mm high water column allowing inspection of
up to 30 mm thick carbon steel materials. Not compatible
with FlexoFORM scanner.
SFA1-Auto-OD8.625
Q7500089 As above, but for 273 mm (10.75 in.) pipe OD SFA1-Auto-OD10.75
Q7500090 As above, but for 324 mm (12.75 in.) pipe OD SFA1-Auto-OD12.75
Q7500091 As above, but for 356 mm (14 in.) pipe OD SFA1-Auto-OD14
Q7500092 As above, but for 406 mm (16 in.) pipe OD SFA1-Auto-OD16
Q7500093 As above, but for 457 mm (18 in.) pipe OD SFA1-Auto-OD18
Q7500094 As above, but for 508 mm (20 in.) pipe OD SFA1-Auto-OD20
Q7500095 As above, but for 559 mm (22 in.) pipe OD SFA1-Auto-OD22
Q7500096 As above, but for 610 mm (24 in.) pipe OD SFA1-Auto-OD24
Q7500097 As above, but for 660 mm (26 in.) pipe OD SFA1-Auto-OD26
Q7500098 As above, but for 711 mm (28 in.) pipe OD SFA1-Auto-OD28
Table 12 FlexoFORM standard wedges (continued)
Part order
number
Description Marketing number
