Olympus FlexoFORM - Table 4 Multiplication Factors for Defect Length Correction Along Index Axis

10-003591-01EN [Q7780031], Rev. 4, January 2020
Chapter 444
Table 4 Multiplication factors for defect length correction along index axis
Pipe OD
(in.)
Defect depth
2mm 3mm 4mm 5mm 6mm 7mm 8mm 9mm 10 mm
1.3 0.57 0.53 0.49 0.45 0.41 0.37 0.33 0.29 0.25
1.66 0.63 0.60 0.57 0.53 0.50 0.47 0.43 0.40 0.37
1.9 0.67 0.64 0.61 0.58 0.55 0.52 0.49 0.46 0.43
2.375 0.72 0.69 0.67 0.64 0.62 0.59 0.56 0.54 0.51
2.875 0.76 0.73 0.71 0.69 0.67 0.65 0.63 0.60 0.58
3.5 0.79 0.77 0.76 0.74 0.72 0.70 0.68 0.66 0.64
4 0.81 0.80 0.78 0.76 0.75 0.73 0.71 0.70 0.68
4.5 0.83 0.82 0.80 0.79 0.77 0.76 0.74 0.73 0.71
6.625 0.88 0.87 0.86 0.85 0.84 0.83 0.82 0.81 0.80
8.625 0.91 0.90 0.89 0.88 0.87 0.86 0.86 0.85 0.84
10.75 0.92 0.92 0.91 0.90 0.90 0.89 0.88 0.88 0.87
12.75 0.94 0.93 0.92 0.92 0.91 0.91 0.90 0.89 0.89
16 0.95 0.94 0.94 0.93 0.93 0.92 0.92 0.91 0.91
22 0.96 0.96 0.95 0.95 0.95 0.94 0.94 0.94 0.93
26 0.97 0.96 0.96 0.96 0.96 0.95 0.95 0.95 0.94
30 0.97 0.97 0.97 0.96 0.96 0.96 0.96 0.95 0.95
34 0.97 0.97 0.97 0.97 0.97 0.96 0.96 0.96 0.96
38 0.98 0.98 0.97 0.97 0.97 0.97 0.97 0.96 0.96
42 0.98 0.98 0.98 0.97 0.97 0.97 0.97 0.97 0.96
48 0.98 0.98 0.98 0.98 0.98 0.97 0.97 0.97 0.97
Flat 111111111
