Table 9 Spare parts
Item
Part order
number
Qty Description
Marketing
number
1 Q8301415 1 Frame handle, side N/A
2 Q8301416 1 Cable attachment, safety lanyard, 152 mm (6 in.) N/A
3 Q8301417 1 Cable sleeve, 5 m N/A
4 Q8301418 1 Lock plate for cable sleeve N/A
5 U8908544 11 Screw, M3 × 10 mm, hex socket cap, stainless N/A
6 Q8301419 1 Main frame, fixed N/A
7 Q8301422 1 Thumb wheel N/A
8 Q8301423 1 Washer, flat, 8.0 mm N/A
9 Q8301424 1 Cotter pin, 3 mm × 6 mm, stainless steel N/A
10 Q8301425 1 Screw, M3 × 35 mm, hex head, stainless N/A
11 Q8301429 1 Name plate N/A
12 Q8301430 1 Shaft, threaded N/A
13 Q8301432 1 Wiper ring N/A
14 Q8301433 1 Encoder, FlexoFORM N/A
15 Q8301481 1 Encoder base, front N/A
16 Q8301482 1 Encoder base, back N/A
17 Q8301426 4 Lock washer, internal tooth, M2 N/A
18
N/A
a
4 Screw, M2 × 6 mm, hex head, stainless N/A
19 Q8301431 1 Encoder wheel N/A
20 U8909086 2 Bearing, flanged, 8 mm ID × 12 mm OD × 3.5 mm W,
stainless
N/A
21 Q8301434 1 Adjustable right-side frame without wheels N/A
22 Q8301435 1 Screw, M6, custom N/A
23 Multiple
available
1 Wedge (see models listed in Table 12 on page 71,
Table 13 on page 72, and Table 14 on page 73)
N/A
24 Q8301441 1 Kit of 20 o-ring seals for water input (on wedge) N/A
25 Q8301442 1 Kit of 10 o-ring seals for probe (on wedge) N/A
