Olympus FlexoFORM - Figure 6-2 Scanner Dimensions

10-003591-01EN [Q7780031], Rev. 4, January 2020
Chapter 662
Figure 6-2 Scanner dimensions
The SFA1-SMALL wedge series dimensions and clearances are shown in Figure 6-3
on page 63, Figure 6-4 on page 64, and in Table 8 on page 64.
100
98.2 mm
(3.87 in.)
260.6 mm
(10.26 in.)
193 mm
(7.6 in.)
100 mm
(3.94 in.)
93.1 mm
(3.66 in.)
101.6 mm
(4.00 in.)
52.5 mm
(2.07 in.)
28.7 mm
(1.13 in.)
38.9 mm
(1.53 in.)
