Olympus FlexoFORM - Figure 3-6 Drawing the Scan Lines on an Elbow

10-003591-01EN [Q7780031], Rev. 4, January 2020
Preparation for Inspection 35
Figure 3-6 Drawing the scan lines on an elbow
Hole for paint
marker
Scan line drawn by
the paint marker
Required indexing
distance
Template marking
tool and paint marker
Distance markings
(in millimeters)
