6.3 Flat Wedge Inspection Surfaces
When fitted with a flat wedge, the FlexoFORM scanner can be used to perform these
inspections on the following parts:
•Flat plates
• Circumferential inspection of pipes:
— With 48 in. and up outside diameters
— With 20 in. and up inside diameters
• Longitudinal inspection of pipes:
— With 200 in. and up outside diameters
The FlexoFORM scanner cannot be used to perform longitudinal inspection of pipes
on the inside surface.
6.4 Cable Connector Pinout
The connector pinout for the scanner interface cable is shown in Figure 6-1 on
page 61.
