Olympus FlexoFORM - Table 12 Flexoform Standard Wedges

10-003591-01EN [Q7780031], Rev. 4, January 2020
Spare Parts and Accessories 71
Q7500063 FlexoFORM scanner kit for corrosion inspection of pipe elbows.
Package includes: Flexible 7.5 MHz, 64 element FA1 phased
array probe, six (6) SFA1 water wedges for 114 mm (4.5 in.),
168 mm (6.625 in.), 219 mm (8.625 in.), 273 mm (10.75 in.),
324 mm (12.75 in.), and 406 mm (16 in.) outside diameters,
encoder cable with LEMO connector compatible with current
generation of OmniScan and FOCUS PX instruments, irrigation
tube, basic spare parts, and accessories packaged in a carrying
case. All cables and tube are 5 m long.
FlexoFORM-
Kit
Q3301201 Flexible phased array probe, 7.5 MHz linear array, 64 elements,
64×7mm total active aperture, 1.00mm pitch, 7mm elevation,
FA1 case type for FlexoFORM scanner, SFA1-SMALL and SFA1-
AUTO wedge series, impedance matching to water, PVC
sheathing, 5 m cable length, OmniScan connector
7.5L64-64X7-
FA1-P-5-OM
Table 12 FlexoFORM standard wedges
Part order
number
Description Marketing number
Q7500067 Standard wedge for flexible array probe (FA1) and
compatible with FlexoFORM scanner. The wedge is used
to generate 0° longitudinal waves and features a
curvature matching 114 mm (4.5 in.) OD for inspection of
extrados and intrados of pipe elbows. The wedge also
features a 9 mm high water column allowing inspection
of up to 30 mm thick carbon steel materials.
SFA1-Flexo-OD4.5
Q7500068 As above, but for 141 mm (5.563 in.) pipe OD SFA1-Flexo-OD5.563
Q7500069 As above, but for 168 mm (6.625 in.) pipe OD SFA1-Flexo-OD6.625
Q7500070 As above, but for 219 mm (8.625 in.) pipe OD SFA1-Flexo-OD8.625
Q7500071 As above, but for 273 mm (10.75 in.) pipe OD SFA1-Flexo-OD10.75
Q7500072 As above, but for 324 mm (12.75 in.) pipe OD SFA1-Flexo-OD12.75
Q7500073 As above, but for 356 mm (14 in.) pipe OD SFA1-Flexo-OD14
Q7500074 As above, but for 406 mm (16 in.) pipe OD SFA1-Flexo-OD16
Q7500075 As above, but for 457 mm (18 in.) pipe OD SFA1-Flexo-OD18
Q7500076 As above, but for 508 mm (20 in.) pipe OD SFA1-Flexo-OD20
Q7500077 As above, but for 559 mm (22 in.) pipe OD SFA1-Flexo-OD22
Table 11 FlexoFORM scanner and probe kits (continued)
Part order
number
Description
Marketing
number
