7
IX73
OM1
PO/OM3
PH/OM4
DIC/OM2
BF/OM5
FL/OM6
ATTENUATOR / DIC
IX3
· IX73P1F
· IX73P2F
Hand switch
U-HSCBM*#
U-CB5S* #
Control box for coded function
· IX3-RFA*
· IX3-RFALFE*
· IX3-RFAL*
IX3-RSPC*
100 W halogen lamp house
· U-LH100L-3
· U-LH100-3+U-RMT
IX3-ILL
Halogen lamp power
supply unit
TH4*
· IX3-RFACA*#
IX3-CBM* #
Control box M
· IX3-RFACS*#
IX3-CAS #
} The modules shown below are only the basic modules. As there are other modules which can be combined with the
microscope but are not shown below, please also refer to the latest Olympus brochures or your dealer.
For information on the modules marked with “*", refer to their instruction manuals.
Modules marked # are components of the IX73 motorized system. Also you can configure the IX73 motorized coded
system in combination with modules marked #. For details, refer to IX3-CBM instruction manual.
Modules marked # are components of the IX73 coded system. For details, refer to U-CB5S instruction manual.
· IX3-LWUCDA #
· IX2-LWUCD
· IX-ULWCD
· IX2-MLWCD*
· U-UCD8*
(Used together
with IX-ADUCD)
Condenser
· IX3-SVR
· BX3-SSU
· IX2-SP
(Used together
with IX-MVR)
· IX2-GS
· GX-SVR
Stage
Eyepieces
· WHN10X
· WHN10X-H
Observation tube
· U-BI90
· U-TBI90
· U-TR30-2
· U-TR30NIR
· U-TR30H-2
(Used together
with IX-ATU)
Microscope frame
6-position revolving
nosepiece
· IX3-D6REA #
· IX3-D6RES #
Motorized fluorescence
illuminator
Coded intermediate
magnification changer
Right side port with C-mount
Motorized / Coded fluorescent
mirror turret
Transmitted light illumination column
1 MODULE NOMENCLATURE
} Install IX3-CBM, U-CB5S and U-LEDPS on top of the other.
U-LEDPS* # #
LED power supply
LED lamp house
IX3-LHLEDC
