Olympus IX73 - Mounting the Lamp Housing

53
IX73
a
2
} This section describes the procedure using the halogen lamp
housing (U-LH100L-3 or U-LH100-3) as an example, but the same
procedure applies to the LED lamp house IX3-LHLEDC.
Loosen the two clamping screws
a
of the illumination column with
the Allen screwdriver provided with the microscope.
Fit the lamp housing to the illumination column
Tighten the two clamping screws
a
of the illumination column.
1
2
3
4
Mounting the Lamp Housing
