Olympus IX73 - Mechanical Stage

11
IX73
Light intensity control knob
Main switch
POWER LED
REMOTE LED
} The applicable halogen bulb is the 12V100WHAL-L.
For details, refer to the separate instruction manual.
Manipulator mounting
screw holes
M6 screw (x 6)
IX-MVR mounting
screw holes
(On both sides)
Plain Stage
IX2-SP
Mechanical Stage
IX-MVR
X-axis knob
Y-axis knob
Y-axis knob
X-axis knob
Mechanical stage with right handle
IX3-SVR
Halogen Lamp Power Supply Unit
TH4
