49
IX73
Item Specification
Optical system UIS2 optical system
Microscope Frame
IX73P1F
IX73P2F
Motorized light path selection
1 100% for observation light path
2 50% for observation light path, 50% for left side port
3 100% for left side port
Focusing movable range Upper side: 6.5 mm or more from the original position
Lower side: 3 mm or more from the original position
Original position: 1 mm above the stage surface
Left side port image magnification: 1X
Illumination Column Column for installing the lamp housing, with 30° tilting mechanism.
Condenser holder up/down movement range: 88 mm
Condenser refocusing mechanism is available.
Designated bulb 12 V, 100 W long-life halogen bulb 12V100WHAL-L (PHILIPS 7724)
Power supply: Halogen lamp power supply unit TH4
Observation
Tube
Type U-BI90 U-TBI90 U-TR30-2/U-
TR30H-2
U-TR30NIR
Binocular Tilting binocular Trinocular Trinocular
Field No. 22
Tube inclination 45° 35° to 85° 30° 30°
Interpupillary
distance adjustment
50 to 76 mm
Diopter adjustment range - 5 to + 5 diop
Intermediate tube U-EPA2, GX-SPU, U-CA, etc. IX-ATU
Light path
selection
None 3 steps:
1 BI 100%
2 BI 20%,
Camera 80%
3 Camera 100%
3 steps:
@ BI 100%
2 BI 50%,
Camera 50%
3 Camera 100%
Stage Type BX3-SSU IX3-SVR IX2-SP
Size 250.5 mm (D) x 268.2 mm (W) 240 mm (D) x 444.5 mm (W) 240 mm (D) x 232 mm (W)
Movement
mechanism
• Ultrasonic drive
• Maximum speed 30 mm/sec
• Single rough/fine adjustment
handle (XY controller)
• X- and Y-axis knob with adjust-
able tension.
• Right long axis handle (can
be mounted by reversing
the right and left)
Not available
Movement range:
52 mm vertical (Y),
76 mm horizontal (X).
Movement range:
75 mm vertical (Y),
114 mm horizontal (X).
Movement range:
(Combined with IX-MVR)
85 mm vertical (Y),
130 mm horizontal (X).
Option Replaceable center plate
(Ø110 mm)
Replaceable center plate
(Ø110 mm)
Replaceable center plate
(Ø110 mm)
Condenser Type
IX3-LWUCDA IX2-LWUCD IX2-MLWCD IX-ULWCD
U-UCD8
(Used together with IX-ADUCD)
NA 0.55 0.55 0.5 0.3 When a dry top lens is used :0.9
When an oil top lens is used :1.4
WD 27 mm 27 mm 45 mm 73 mm When a dry top lens is used :1.5 mm
When an oil top lens is used :0.6 mm
Turret small hole 3,
large hole 4
small hole 3,
large hole 2
4 4
small hole 3,
large hole 5
Operating
environment
· Indoor use.
· Altitude: Max. 2000 meters
· Ambient temperature: 5 to 40 °C (41 to 104 °F)
· Maximum relative humidity: 80 % for temperatures up to 31 °C (88 °F) (without condensation)
In case of over 31 °C (88 °F), the relative humidity is decreased linearly through 70 % at 34 °C (93 °F),
60 % at 37 °C (99 °F), and to 50 % at 40 °C (104 °F).
· Supply voltage fluctuations: ±10%
· Pollution degree: 2 (in accordance with IEC60664-1)
· Installation/Overvoltage category: II (in accordance with IEC60664-1)
Transportation/
storage environment
· Temperature: Min. -25°C, Max. 65°C
· Humidity: Min. 0%, Max. 90% (without condensation)
8 SPECIFICATIONS
