<< Attaching to MX63L >>
Adapter
MX-HGAD
Light guide adapter
U-LLGAD
Double lamp housing adapter
U-DULHA
Reflected LED
light source
BX3M-LEDR
Darkfield converter
U-RCV
Halogen lamp housing
U-LH100L-3
Mercury lamp
housing
U-LH100HG
U-LH100HGAPO
Layout of the extension cable for reflected LED light source
If you want to connect the light source for reflected LED to the
microscope frame using the double lamp housing adapter (U-DULHA),
the extension cable (MX-LLHECBL) is required. Attach the cable holder
b
provided with the extension cable as shown in the picture, and lay
out the cable so that the cable does not contact the lamp housing, etc.
a
b
