93
MX63/MX63L
93
Attaching two lamp housings
· The attachable lamp housings or adapters are restricted in combinations, orders and directions. (See
the diagram below.)
· Attach the double lamp housing adapter (U-DULHA) so that the illuminator
a
comes to the left side
horizontally when facing to the back side of the microscope frame.
<< Attaching to MX63 >>
Adapter
MX-HGAD
Darkfield converter
U-RCV
Liquid light guide adapter
U-LLGAD
Double lamp housing adapter
U-DULHA
Reflected LED
light source
BX3M-LEDR
Halogen lamp housing
U-LH100L-3
Mercury lamp
housing
U-LH100HG
U-LH100HGAPO
a
To Next Page
