Prior to performing the calibration, firmly fix the terminal and do not change its
position during operation.
Automatic calibration is recommended for vehicles that are operated mainly at speeds
above 50 km/h. Automatic calibration takes from 2 minutes to 24 hours depending on
the frequency of accelerations and braking on straight sections of the road.
When selecting manual calibration, in the “Position of the terminal” field, select one of
24 positions as shown in figure:
Arrow ► indicates the location of
the terminal connector.
The “Omnicomm” inscription in
the figure corresponds to the
top cover of the terminal.
Deflection of the terminal from the axes during manual calibration should not be
more than 5 degrees.
In the “Settings” tab select the “Driving Control” section from the list.
“Control of dangerous driving” – enable/disable registration of dangerous driving
when exceeding the set values of monitored parameters.
