Omron C200H - Double Binary-To-Double Bcd - Bcdl(59); Hours-To-Seconds - Hts(65)

151
5-16-4 DOUBLE BINARY-TO-DOUBLE BCD – BCDL(59)
S: First source word (binary)
IR, SR, AR, DM, HR, LR
R: First result word
IR, AR, DM, HR, LR
Ladder Symbols Operand Data Areas
BCDL(59)
S
R
@BCDL(59)
S
R
If the content of S exceeds 05F5E0FF, the converted result would exceed
99999999 and BCDL(59) will not be executed. When the instruction is not
executed, the content of R and R+1 remain unchanged.
BCDL(59) converts the 32-bit binary content of S and S+1 into eight digits of
BCD data, and outputs the converted data to R and R+1.
S + 1 S
R + 1 R
BCD
Binary
Flags ER: Content of R and R+1 exceeds 99999999.
Indirectly addressed DM word is non-existent. (Content of *DM word
is not BCD, or the DM area boundary has been exceeded.)
EQ: ON when the result is zero.
5-16-5 HOURS-TO-SECONDS – HTS(65)
S: Beginning source word (BCD)
IR, SR, AR, DM, HR, TC, LR
R: Beginning result word (BCD)
IR, SR, AR, DM, HR, TC, LR
Ladder Symbols
Operand Data Areas
---: Not used.
HTS(65)
S
R
---
@HTS(65)
S
R
---
Limitations Can be performed with the CPU11-E only. S and S+1 must be within the
same data area. R and R+1 must be within the same data area. S and S+1
must be BCD and must be in the proper hours/minutes/seconds format.
Description HTS(65) is used to convert time notation in hours/minutes/seconds to an
equivalent in just seconds.
Limitations
Description
Data Conversion Section 5-16
