A number of other error messages are detailed within this manual. Errors in
program input and debugging can be examined in Section 4 and errors in
cassette tape operation are detailed in Section 7-2.
8-5 Error Flags
The following table lists the flags and other information provided in the SR
and AR areas that can be used in troubleshooting. Details are provided in 3-4
SR Area and 3-5 AR Area.
SR Area
Address(es) Function
23600 to 23615 Node loop status for SYSMAC NET Link system
23700 to 23715 Completion/error code output area for SEND(90)/RECV(98) in
SYSMAC LINK/SYSMAC NET Link System
24700 to 25015 PC Link Unit Run and Error Flags
25100 to 25115 Remote I/O Error Flags
25200 SYSMAC LINK/SYSMAC NET Link Level 0 SEND(90)/RECV(98)
Error Flag
25203 SYSMAC LINK/SYSMAC NET Link Level 1 SEND(90)/RECV(98)
Error Flag
25206 Rack-mounting Host Link Unit Level 1 Error Flag
25208 CPU-mounting Host Link Unit Error Flag
25300 to 25307 FAL number output area.
25308 Low Battery Flag
25309 Cycle Time Error Flag
25310 I/O Verification Error Flag
25311 Rack-mounting Host Link Unit Level 0 Error Flag
25312 Remote I/O Error Flag
25415 Special I/O, Master, or Link Unit Error Flag
25503 Instruction Execution Error (ER) Flag
Other Error Messages
Error Flags Section 8-5
