269
AR Area
Address(es) Function
0000 to 0009 Special I/O or PC Link Unit Error Flags
0010 SYSMAC LINK/SYSMAC NET Link Level 1 System
Error Flags
0011 SYSMAC LINK/SYSMAC NET Link Level 0 System
Error Flags
0012 Rack-mounting Host Link Unit Level 1 Error Flag
0013 Rack-mounting Host Link Unit Level 0 Error Flag
0014 Remote I/O Master Unit 1 Error Flag
0015 Remote I/O Master Unit 0 Error Flag
0200 to 0204 Error Flags for Slave Racks 0 to 4
0300 to 0315 Optical I/O Units (0 to 7) Error Flags
0400 to 0415 Optical I/O Units (8 to 15) Error Flags
0500 to 0515 Optical I/O Units (16 to 23) Error Flags
0600 to 0615 Optical I/O Units (24 to 31) Error Flags
0713 to 0715 Error History Bits
1114 Communications Controller Error Flag Level 0
1115 EEPROM Error Flag for operating level 0
1514 Communications Controller Error Flag Level 1
1515 EEPROM Error Flag for operating level 1
2404 CPU11-E Low Battery Flag
2500 to 2515 FALS-generating address or cycle time error (BCD)
Error Flags Section 8-5
