Omron C200H - Binary Multiply - Mlb(52)

183
#0000 – 6851 –1 (from CY = 1) = 0000 + (10000 – 6851 – 1) = 97AE.
The content of HR 12, #0001, indicates a negative result.
R: HR 10
F92D
Mi: IR 010
5A10
Su: DM 0100
60E3
–
R: HR 11
6851
Mi: IR 011
20F5
Su: DM 0101
B8A3
–
CY = 1
Lower 4 digits. Higher 4 digits.
CY = 1
R+2: HR 12 R+1: HR 11 R: HR 10
000197AE06D3
5A10 + (10000 – 60E3)
–
00010000
–
20F5 + (10000 – B8A3) – 1
CY = 0
(from CLC(41))
5-18-3 BINARY MULTIPLY – MLB(52)
Md: Multiplicand word (binary)
IR, SR, AR, DM, HR, TC, LR, #
Mr: Multiplier word (binary)
IR, SR, AR, DM, HR, TC, LR, #
Ladder Symbols
Operand Data Areas
R: First result word
IR, AR, DM, HR LR
MLB(52)
Md
Mr
R
@MLB(52)
Md
Mr
R
When the execution condition is OFF, MLB(52) is not executed. When the
execution condition is ON, MLB(52) multiplies the content of Md by the con-
tents of Mr, places the rightmost four digits of the result in R, and places the
leftmost four digits in R+1.
Md
Mr
R +1 R
X
Flags ER: Indirectly addressed DM word is non-existent. (Content of *DM word
is not BCD, or the DM area boundary has been exceeded.)
EQ: ON when the result is 0.
Description
Binary Calculations Section 5-18
