281
Appendix B
Programming Instructions
This appendix provides tables listing the programming instructions used with C200H PCs. The first table sum-
marizes all instructions and gives page references where more detailed information can be found in the body
of the manual. The second table gives the execution times for the instructions for both ON and OFF execution
conditions. The third part is divided into two tables and summarizes the instructions, giving the ladder diagram
symbol, a brief description, and the applicable data areas. In all tables, the entries are listed alphanumerically.
Instructions without function codes are given first in alphabetical order, according to the mnemonic. These are
followed by the instructions with function codes which are listed numerically, according to the function code.
A PC instruction is entered either using the appropriate Programming Console key(s) (e.g., LD, AND, OR,
NOT), or by using function codes. To input an instruction using its function code, press FUN, the function
code, and then WRITE.
Function Code Name Mnemonic Page
-- AND AND 102
-- AND LOAD AND LD 103
-- AND NOT AND NOT 102
-- COUNTER CNT 118
-- LOAD LD 102
-- LOAD NOT LD NOT 102
-- OR OR 102
-- OR LOAD OR LD 103
-- OR NOT OR NOT 102
-- OUTPUT OUT 104
-- OUTPUT NOT OUT NOT 104
-- TIMER TIM 113
00 NO OPERATION NOP 112
01 END END 111
02 INTERLOCK IL 108
03 INTERLOCK CLEAR ILC 108
04 JUMP JMP 110
05 JUMP END JME 110
06 FAILURE ALARM FAL 202
07 SEVERE FAILURE ALARM FALS 202
08 STEP DEFINE STEP 193
09 STEP START SNXT 193
10 SHIFT REGISTER SFT 123
11 KEEP KEEP 106
12 REVERSIBLE COUNTER CNTR 121
13 DIFFERENTIATE UP DIFU 105
14 DIFFERENTIATE DOWN DIFD 105
15 HIGH-SPEED TIMER TIMH 117
16 WORD SHIFT WSFT 130
17 REVERSIBLE WORD SHIFT RWS 131
18 CYCLE TIME SCAN 203
19 MULTI-WORD COMPARE MCMP 141
