213
Indirectly addressed DM word is non-existent. (Content of *DM word
is not BCD, or the DM area boundary has been exceeded.)
There is no SYSMAC NET Link/SYSMAC LINK Unit.
5-23-2 NETWORK RECEIVE – RECV(98)
S: Source beginning word
IR, SR, AR, DM, HR, TC, LR
D: Destination beginning word
IR, AR, DM, HR, TC, LR
Operand Data Areas
C: First control data word
IR, AR, DM, HR, TC, LR
Ladder Symbols
RECV(98)
S
D
C
@RECV(98)
S
D
C
Limitations Can be performed with the CPU11-E only. C through C+2 must be within the
same data area and must be within the values specified below. To be able to
use RECV(98), the system must have a SYSMAC NET Link or SYSMAC
LINK Unit mounted.
When the execution condition is OFF, RECV(98) is not executed. When the
execution condition is ON, RECV(98) transfers data beginning at S from a
node on the SYSMAC NET Link/SYSMAC LINK System to words beginning
at D. The control words, beginning with C, provide the number of words to be
received, the source node, and other transfer parameters.
The status of bit 15 of C+1 determines whether the instruction is for a
SYSMAC NET Link System or a SYSMAC LINK System.
Control Data
SYSMAC NET Link Systems The source port number is always set to 0. Set the network number to 0 to
receive data to a node on the same Subsystem (i.e., network). Refer to the
SYSMAC NET Link System Manual for details.
Word Bits 00 to 07 Bits 08 to 15
C Number of words (0 to 1000 in 4-digit hexadecimal, i.e., 0000
hex
to 03E8
hex
)
C+1 Network number (0 to 127 in 2-digit
hexadecimal, i.e., 00
hex
to 7F
hex
)
Bit 14 ON: Operating level 0
OFF: Operating level 1
Bits 08 to 13 and 15:
Set to 0.
C+2 Source node (1 to 126 in 2-digit
hexadecimal, i.e., 01
hex
to 7E
hex
)
Source port
NSB: 00
NSU: 01/02
Description
SYSMAC NET Link/SYSMAC LINK Instructions Section 5-23
