35
Level 0 Level 1 Bit (body of table shows node numbers)
00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15
AR 08 AR 12 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
AR 09 AR 13 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
AR 10 AR 14 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
AR 11 AR 15 49 50 51 52 53 54 55 56 57 58 59 60 61 62 * **
*Communication Controller Error Flag
**EEPROM Error Flag
3-5-5 SYSMAC LINK/SYSMAC NET Link System Service Time
(CPU11-E only)
AR 16 provides the time allocated to servicing operating level 0 of the SYS-
MAC LINK System and/or SYSMAC NET Link System during each cycle
when a SYSMAC LINK Unit and/or SYSMAC NET Link Unit is mounted to a
Rack.
AR 17 provides the time allocated to servicing operating level 1 of the SYS-
MAC LINK System and/or SYSMAC NET Link System during each cycle
when a SYSMAC LINK Unit and/or SYSMAC NET Link Unit is mounted to a
Rack.
These times are recorded in 4-digit BCD to tenths of a millisecond (000.0 ms
to 999.9 ms) and are refreshed every cycle.
Bits
15 to 12 11 to 08 07 to 04 03 to 00
10
2
10
1
10
0
10
–1
3-5-6 Calendar/Clock Area and Bits (CPU11-E Only)
Calendar/Clock Area If AR 2114 (Stop Bit) is OFF, then the date, day, and time will be available in
BCD in AR 18 to AR 20 and AR 2100 to AR 2108 as shown below. This area
can also be controlled with AR 2113 (Seconds Round-off Bit) and AR 2115
(Set Bit).
Bits Contents Possible values
AR 1800 to AR 1807 Seconds 00 to 59
AR 1808 to AR 1815 Minutes 00 to 59
AR 1900 to AR 1907 Hours 00 to 23 (24-hour system)
AR 1908 to AR 1915 Day of month 01 to 31 (adjusted by month and for leap year)
AR 2000 to AR 2007 Month 1 to 12
AR 2008 to AR 2015 Year 00 to 99 (Rightmost two digits of year)
AR 2100 to AR 2107 Day of week 00 to 06 (00: Sunday; 01: Monday; 02: Tuesday; 03: Wednesday; 04:
Thursday; 05: Friday; 06: Saturday)
Seconds Round-off Bit AR 2113 is turned ON to round the seconds of the Calendar/clock Area to
zero, i.e., if the seconds is 29 or less, it is merely set to 00; if the seconds is
30 or greater, the minutes is incremented by 1 and the seconds is set to 00.
Stop Bit AR 2114 is turned OFF to enable the operation of the Calendar/clock Area
and ON to stop the operation.
Set Bit AR 2115 is used to set the Calendar/clock Area as described below. This
data must be in BCD and must be set within the limits for the Calendar/clock
Area given above.
AR Area Section 3-5
