Appendix AStandard Models
279
SYSMAC LINK Unit/SYSMAC NET Link Unit
If you are using any of the Units listed in the table below, they must be
mounted to a CPU Rack that uses model C200H-CPU11-E as the CPU.
Otherwise, these Units will not operate properly.
Name Specifications Model number
SYSMAC LINK Unit Must be mounted to leftmost 2 slots on Rack with
C200H-CPU11-E. Use optical fiber cable.
C200HW-SLK13/14
Must be mounted to leftmost 2 slots on Rack
with C200H-CPU11-E
C200HW-SLK23/24-V1
Terminator One required for each node at ends of System C1000H-TER01
Attachment Stirrup Provided with SYSMAC LINK Unit C200H-TL001
F Adapter --- C1000H-CE001
F Adapter Cover --- C1000H-COV01
Communications
Cbl
Coaxial cables Manufactured by Hitachi ECXF5C-2V
Cable
Manufactured by Fujigura 5C-2V
Auxiliary Power Sup-
ply Unit
For use with the C200H-SLK11 C200H-APS03
SYSMAC NET Link Unit Must be mounted to leftmost 2 slots on Rack with
C200H-CPU11-E
C200HS-SNT32
Power Supply
Ad t
Required when supplying power from Central
PSl
For 1 Unit C200H-APS01
pp y
Adapter
qppygp
Power Supply
For 2 Units C200H-APS02
Power Cable
Connects Power Supply Adapter and
SYSMAC NET Li k U it
For 1 Unit C200H-CN111
pp y p
SYSMAC NET Link Unit
For 2 Units C200H-CN211
Bus Connection Unit
Connects SYSMAC LINK Unit or SYSMAC
NET Li k U it t CPU
For 1 Unit C200H-CE001
NET Link Unit to CPU
For 2 Units C200H-CE002
