Some example Di values and the word-to-digit conversions that they produce
are shown below.
0
1
2
3
R
Di: 0011
S
S + 1
0
1
2
3
S
S + 1
S + 2
S + 3
Di: 0030
R
S
S + 1
S + 2
S + 3
0
1
2
3
Di: 0032
R
Di: 0013
0
1
2
3
S
S + 1
R
Flags ER: Undefined digit designator, or S plus number of digits exceeds a data
area.
Content of a source word is zero.
Indirectly addressed DM word is non-existent. (Content of *DM word
is not BCD, or the DM area boundary has been exceeded.)
When 00000 is ON, the following diagram encodes IR words 010 and 011 to
the first two digits of HR 20 and then encodes LR 10 and 11 to the last two
digits of HR 20. Although the status of each source word bit is not shown, it is
Example
Data Conversion Section 5-16
