Omron C200H - Page 244

232
Instruction
OFF execution time (
µs)ON execution time (µs)
Conditions
BCMP(68) Comparing constant to word-designated
table
674 3.75
Comparing *DM b *DM-designated table
926
VCAL69) Trigonometric functions. 488 3.75
Linear approximation with a 256 word
table
2.71 ms
XFER(70) When transferring 1 word 305 3.75
When transferring 1,000 words using
*DM
16 ms
BSET(71) When setting a constant to 1 word 209 3.75
When setting *DM ms to 1,000 words
using *DM
4.28 ms
ROOT(72) When taking root of word and placing in a
word
631 3
When taking root of 99,999,999 in *DM
and placing in *DM
1.16 ms
XCHG(73) Between words 156 3
Between *DM
316
SLD(74) When shifting 1 word 193 3
When shifting 1,000 DM words using *DM
33 ms
SRD(75) When shifting 1 word 193 3
When shifting 1,000 DM words using *DM
33 ms
MLPX(76) When decoding word to word 203 3.75
When decoding *DM to *DM
568
DMPX(77) When encoding a word to a word 225 3.75
When encoding *DM to *DM
551
SDEC(78) When decoding a word to a word 235 3.75
When decoding *DM to *DM
571
FDIV(79)
Word ÷ word b word (equals 0)
632 3.75
Word ÷ word b word (doesn’t equal 0)
1.77 ms
*DM ÷ *DM b *DM
2.1 ms
DIST(80) Constant b word + (word) 246 3.75
*DM b (*DM + (*DM))
481
COLL(81) (Word + (word)) b word 262 3.75
(*DM + (*DM)) b *DM
497
MOVB (82) When transferring word to a word 158 3.75
When transferring *DM to *DM
357
MOVD(83) When transferring word to a word 195 3.75
When transferring *DM to *DM
399
SFTR(84) When shifting 1 word 284 3.75
When shifting 1,000 DM words using *DM
13.8 ms
TCMP(85) Comparing constant to words in a
designated table
542 3.75
Comparing *DM b *DM-designated table
830
Instruction Execution Times Section 6-3
