Appendix AStandard Models
272
C200H I/O Units
Name Specifications Model number
Input Units AC Input Unit 8 pts 100 to 120 VAC C200H-IA121
16 pts 100 to 120 VAC C200H-IA122
8 pts 200 to 240 VAC C200H-IA221
16 pts 200 to 240 VAC C200H-IA222
DC Input Unit 8 pts No-voltage contact; NPN C200H-ID001
8 pts No-voltage contact; PNP C200H-ID002
8 pts 12 to 24 VDC C200H-ID211
16 pts 24 VDC C200H-ID212
AC/DC Input Unit 8 pts 12 to 24 VAC/DC C200H-IM211
16 pts 24 VAC/DC C200H-IM212
Analog Timer
Unit
4 timers 0.1 to 1 s, 1 to 10 s, 10 to 60 s, or 1
min to 10 min (switchable)
C200H-TM001
Variable Resistor
Connector
(Related Product)
Connector with lead wire (2 m) for 1
external resistor
C4K-CN223
Output
Units
Relay Output Unit 8 pts 2 A, 250 VAC/24 VDC (For resistive
loads)
C200H-OC221
12 pts 2 A, 250 VAC/24 VDC (For resistive
loads)
C200H-OC222
16 pts 2 A, 250 VAC/24 VAC (For resistive
loads)
C200H-OC225
5 pts 2 A, 250 VAC/24 VDC (For resistive
loads)
Independent commons
C200H-OC223
8 pts 2 A, 250 VAC/24 VDC (For resistive
loads)
Independent commons
C200H-OC224
Triac Output Unit 8 pts 1 A, 120 VAC C200H-OA121-E
8 pts 1 A, 250 VAC C200H-OA221
12 pts 0.3 A, 250 VAC C200H-OA222
Transistor Output
Uit
8 pts 1 A, 12 to 48 VDC C200H-OD411
p
Unit
12 pts 0.3 A, 24 VDC C200H-OD211
16 pts 0.3 A, 24 VDC C200H-OD212
8 pts 2.1 A, 24 VDC C200H-OD213
8 pts 0.8 A, 24 VDC; source type (PNP);
with load short protection
C200H-OD214
8 pts 0.3 A, 5 to 24 VDC; source type
(PNP)
C200H-OD216
12 pts 0.3 A, 5 to 24 VDC; source type
(PNP)
C200H-OD217
B7A Interface Units
15 or
16 input
pts
Connects to B7A Link Terminals.
C200H-B7AI1
16 out-
put pts
C200H-B7AO1
Transistor Output Unit C200H-OD212 and Contact Output Unit C200H-
OC225 must be mounted to either a C200H-BC031-V2, C200H-BC051-V2,
C200H-BC081-V2, or C200H-BC101-V2 Backplane.
Note
