Appendix BProgramming Instructions
285
Instruction
OFF execution time (
µs)ON execution time (µs)
Conditions
SNXT(09) --- 34 2.25
SFT(10) With 1-word shift register 181 R: 191
IL: 30
JMP: 30
With 250-word shift register 1.44 ms R: 1.81 ms
IL: 30
JMP: 30
KEEP(11) --- 1.13 ---
CNTR(12) Constant for SV 111 R: 85
IL: 49
*DM for SV
205 JMP: 49
DIFU(13) --- 93 Normal: 93
IL: 93
JMP: 84
DIFD(14) --- 92 Normal: 92
IL: 92
JMP: 84
TIMH(15) Interrupt Constant for SV 120 R: 199
Normal cycle 135 IL: 199
Interrupt *DM for SV
120 JMP: 73
Normal cycle 135 R: 291
IL: 291
JMP: 73
WSFT(16) When shifting 1 word 170 3
When shifting 1,000 words using *DM
8.6 ms
RWS(17) When resetting 1 word 388 3.75
When shifting 999 words using *DM
30.3 ms
SCAN(18) Constant for SV 311 3.75
*DM for SV
412
MCMP(19) Comparing 2 words, result word 636 3.75
Comparing 2 *DM, result *DM
890
CMP(20) When comparing a constant to a word 124 3
When comparing two *DM
296
MOV(21) When transferring a constant to a word 88 3
When transferring *DM to *DM
259
MVN(22) When transferring a constant to a word 91 3
When transferring *DM to *DM
261
BIN (23) When converting a word to a word 174 3
When converting *DM to *DM
338
BCD(24) When converting a word to a word 179 3
When converting *DM to *DM
337
ASL(25) When shifting a word 72 2.25
When shifting *DM
158
