Data Areas Appendix E
332
Word(s) FunctionBit(s)
01 14/15 Remote I/O Master Unit 1/Unit 0 Restart Bits
02 00 to 04 Error Flags for Slave Racks 0 to 4
05 to 15 Not used.
03 00 to 15 Error Flags for Optical I/O Units 0 to 7
04 00 to 15 Error Flags for Optical I/O Units 8 to 15
05 00 to 15 Error Flags for Optical I/O Units 16 to 23
06 00 to 15 Error Flags for Optical I/O Units 24 to 31
07 00 to 03 Data Link setting for operating level 0 of SYSMAC LINK System
04 to 07 Data Link setting for operating level 1 of SYSMAC LINK System
08 TERMINAL Mode Input Cancel Bit (CPU11-E only)
09 to 12 Not used.
13 to 15 Error History Area (13: Overwrite Bit, 14: Reset Bit, 15: Enable Bit) (CPU11-E only)
08 to 11 00 to 15 Active Node Flags for SYSMAC LINK System nodes of operating level 0
12 to 15 00 to 15 Active Node Flags for SYSMAC LINK System nodes of operating level 1
16 00 to 15 SYSMAC LINK/SYSMAC NET Link System operating level 0 service time per cycle
17 00 to 15 SYSMAC LINK/SYSMAC NET Link System operating level 1 service time per cycle
18 to 21 00 to 15 Calendar/Clock Area (CPU11-E only)
22 00 to 15 TERMINAL Mode Key Bits (CPU11-E only)
23 00 to 15 Power-OFF Counter
24 00 to 03 Not used.
04 CPU Unit Low Battery Flag (CPU11-E only)
05 Cycle Time Flag
06 SYSMAC LINK System Network Parameter Flag for operating level 1
07 SYSMAC LINK System Network Parameter Flag for operating level 0
08 SYSMAC LINK/SYSMAC NET Link Unit Level 1 Mounted Flag
09 SYSMAC LINK/SYSMAC NET Link Unit Level 0 Mounted Flag
10 to 12 Not used.
13 Rack-mounting Host Link Unit Level 1 Mounted Flag
14 Rack-mounting Host Link Unit Level 0 Mounted Flag
15 CPU-mounting Device Mounted Flag
25 00 to 15 FALS-generating Address
26 00 to 15 Maximum Cycle Time
27 00 to 15 Present Cycle Time
