CK3WConfigErr
Register name Sys.CK3WConfigErr
Description There is an error in the CK3W hardware configuration.
Range 0 to 7
Details Checks that there are no errors in the configurations of the connected CK3W Unit and
End Cover
.
0: No hardware configuration error
1: No End Cover
2: Five or more CK3W Units are installed to the CPU Rack or Expansion Rack, except
for the Expansion Master Unit and Expansion Slave Unit.
3: Reserve
4: Three or more Axis Interface Units are installed to the CPU Rack or Expansion Rack.
5: The Expansion Master Unit is not installed adjacent to the right side of the CPU Unit.
6: Reserve
7: Address switches overlap.
When an error occurs, the Unit number counted from the CPU Unit at which the error
was detected is written to the Sys.CK3WConfigCount register. However, the CK3W-
EXS02 (Expansion Slave Unit) is excluded from the count.
If Sys.CK3WConfigCount is “0”, it shows that an error was detected in the CPU Unit. If
Sys.CK3WConfigCount is “1”, it shows that an error was detected in the Unit installed
next to the CPU Unit.
Detection timing When power is turned ON or reset
Recovery Cycle the power supply, reset command ($$$)
Effects Operation continues
Cause and cor-
rection
Cause (Assumed cause) Correction Prevention
No End Cover Attach an End Cover None
Three or more CK3W-AX
Units are connected to the
CPU Rack or Expansion
Rack.
Reduce the number of
CK3W
-AX Units connected
to two or less.
None
The CK3W Unit address
switch value is used more
than once.
Set a unique address to
prevent duplication of the
address switch value.
None
Five or more CK3W Units
are installed to the CPU
Rack or Expansion Rack,
except for the Expansion
Master Unit and Expansion
Slave Unit.
Reduce the number of
CK3W Units connected to
four or less in each rack.
None
The Expansion Master Unit
is not installed adjacent to
the right side of the CPU
Unit.
Install the Expansion Mas-
ter Unit adjacent to the right
side of the CPU Unit.
None
Contamination with conduc-
tive object
If there is conductive mate-
rial nearby
, blow air through
the Unit.
Do not perform any metal
work in the vicinity of the
control panel.
Make sure that the work en-
vironment is free of dirt and
dust.
Then close the control pan-
el.
6 Troubleshooting
6-11
CK3M-series Programmable Multi-Axis Controller User's Manual Hardware (O036)
6-4 Sys.Status Register
6
6-4-2 Details of Flags
