6 - 1
6
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
This section describes how to perform online debugging of the FH sensor controller.
6-1 Performing Test Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
6-1-1 Measuring Camera Images . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
6-1-2 Measuring File Images in the RAMDisk or the External Memory,
i.e. USB Memory of the Vision Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
6-1-3 Measuring Logging Images in the Vision Sensor Memory . . . . . . . . . . . . . . . . 6-3
6-2 Checking Measurement Results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
6-2-1 Checking Detailed Results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
6-2-2 Changing the Image Display Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
6-2-3 Checking Multiple Measurement Images at the Same Time . . . . . . . . . . . . . . 6-6
6-3 Checking Result Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
6-4 Saving Measurement Results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
6-5 Saving Settings Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
Online Debugging

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
