Omron fh series Operation Manual

6 - 9
6 Online Debugging
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
6-5 Saving Settings Data
6
6-5 Saving Settings Data
After adjusting the settings data, you need to save the settings data to the flash memory of the FH
vision sensor. There are the following two ways to save the settings data.
(1) Right-click [Configuration and Setup] - [Device Group] - [FH-XXXX] - [Line X] in the Multiv-
iew Explorer and then click [Save data].
(2) Click the [Data save] button in the scene maintenance window.
The settings data can also be saved and managed as files.
• Scene data basis (Refer to 2-5-2 Managing Scenes on page 2-26)
• Scene group basis (Refer to 2-5-6 Managing Scene Groups on page 2-28)
• Processing unit basis (Refer to 2-6-2 Managing Processing Units on page 2-32)

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
