4 Configuring Measurement Settings
4 - 10
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
You can specify any color.
The color can be specified by specifying the hue, saturation, and brightness.
The specifications are the same as for the user interface of the FH vision sensor.
For details, refer to Vision System FH/FZ5 Series Processing Item Function Reference Manual (Cat.
No. Z341).
You can specify the range of binarization levels.
If you select the [Binary Reverse] check box, binarization is performed for outside of the range between
the upper and lower limits.
4-2-4 Color
4-2-5 Binary
