2 Basic Operations
2 - 6
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
2-3 Creating a New Project
This section describes how to create a new project file. For details on the basic operations, refer to 3-3
Creating a Project in Sysmac Studio Version 1 Operation Manual (Cat. No. W504-E1-08 or later).
Here, we describe how to create a new project for the FH vision sensor (hereinafter referred to as "FH
project").
1 Click the [New Project] button in the project window.
2 In the [Project Properties] dialog box, enter the information in [Project name], [Author] (optional),
and [Comment] (optional), select the following device from [Category] and [Device] of [Select
Device], and click the [Create] button.
2-3-1 Creating a New Project File from the Project Window
Item Setting
Category Vision sensor
Device FH
