9 - 5
9 Limitations
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
9-2 Synchronization with the NJ/NX-series Controllers
9
9-2 Synchronization with the
NJ/NX-series Controllers
Consider the following limitations when synchronizing the project with the NJ/NX-series controller to
which the FH vision sensor is connected.
z
Downloading ([Transfer to Controller])
The setting data in FH vision sensor are not downloaded.
To download the setting data in FH vision sensor, establish an online connection for the vision
sensor. Refer to 2-8 Precautions on Synchronization through an NJ/NX-series Controller on page
2-39.
The global variables allocated to the FH vision sensor I/O ports in the I/O Map are downloaded.
z
Uploading ([Transfer to computer])
The setting data in FH vision sensor are not uploaded.
The FH vision sensor setting data are initialized after uploading. Be sure to establish an online
connection for FH vision sensor before the synchronization. Refer to 2-8 Precautions on Synchro-
nization through an NJ/NX-series Controller on page 2-39.
The global variables allocated to the FH vision sensor I/O ports in the I/O Map are downloaded.
For details on the synchronization to the NJ/NX-series controller, refer to Sysmac Studio Version 1
Operation Manual (Cat. No. W504).
