6-4 Saving Measurement Results
If you wish to save measurement results or images, use the logging related processing units.
• Image logging
• Image conversion logging
• Data logging
Using these processing unites, allow to output the measurement results to the FH Vision Sensor or the
external memory,i.e. USB memory.
For details on the processing units, refer to Vision System FH/FZ5 Series Processing Item Function
Reference Manual (Cat. No. Z341).
To acquire the files output to the RAMDisk or the external memory, i.e. USB memory of the FH Vision
Sensor, use the file management tool.
For details, refer to 8-3 Using the File Save Tool on page 8-4.
