Omron fh series Operation Manual

8 - 19
8 Other Useful Functions
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
8-13 Using the Scene Control Macro Tool
8
8-13 Using the Scene Control Macro Tool
With this tool, it is possible to supplement and expand measurement flow and scene control.
This function is the same as the [
Scene Control macro tool] function under the [Tool] menu in the FH
vision sensor. For details, refer to Vision System FH/FZ5 Series User's Manual (Cat. No. Z365) or
Vision System FH/FZ5 series Macro Customize Functions Programming Manual (Cat. No. Z367).

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
