4 Configuring Measurement Settings
4 - 6
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
You can edit a model area or measurement area.
Click the area editing button to display the area editing menu.
Six area editing functions are provided.
This function draws a rectangle. You can change the size of the rectangle by dragging the four corners.
The rectangle can be moved by clicking and then dragging the inside of the rectangle.
Before clicking
After clicking
Combo box Selects one item from multiple selection items.
4-2-2 Editing an Area
Rectangle
UI Item Description
ĺ

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
