4 Configuring Measurement Settings
4 - 4
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
4-2 Editing a Processing Unit
Right-click any processing unit in the flow list and then select [Edit] from the menu.
The editing screen of the selected processing unit appears.
The editing screens of processing units are categorized into the following two types.
Each setting menu can be opened and closed on a group basis. In an editing screen with image dis-
play, an image or graphic information is displayed in accordance with the open menu.
Clicking the [OK] button confirms the changes and closes the editing screen of the processing unit.
Clicking the [Cancel] button discards the changes and closes the editing screen of the processing unit.
The basic editing operations that can be performed with this tool are described below.
<Editing Screen with Image Display>
<Editing Screen without Image Display>

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
