Omron fh series Operation Manual

9 Limitations
9 - 4
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
Precautions for Correct Use
The below application will run while the FH vision sensor is being edited offline.
FZ-CoreRA 0.exe
Do not attempt to exit this application manually. Exiting this application prematurely may cause
problems to arise with the FH editing. Should the application be closed accidentally, end Sys-
mac Studio, restart the computer, and try again.
Elapsed Time żż
Parallelize żż
Parallelize Task żż
Conditional Branch żż
DI Branch żż
End żż
Selective Branch żż
Control Flow Normal żż
Control Flow PLC Link żż
Control Flow Parallel żż
Control Flow Fieldbus żż
Parallel Judgment Output żż
Data Output żż
Parallel Data Output żż
Fieldbus Data Output żż
Result Display żż
Display Image File żż
Display Last NG Image żż
Conveyor Panorama Display
ż
*3
ż
*3
*1. Sysmac Studio ver.1.09 or later is required to register and edit the processing item(s).
*2. FH Sensor Controller ver.5.20 or later is required to register and edit the processing item(s).
*3. FH Sensor Controller ver.5.50 or later is required to register and edit the processing item(s).
ż: Supported, x: Not supported
Processing Unit Registration Editing

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
