8 - 5
8 Other Useful Functions
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
8-3 Using the File Save Tool
8
8-3-2 Copying a File
1 Select [File] for [Target data].
2 Select a file.
You can select data on a folder basis or on a file basis.
If you select an individual folder, you can narrow down the files by type.
The following file types can be selected to narrow down the data.
• All files
• Logging images (*.ifz, *.byr)
• Bitmap (*.bmp)
• CSV (*.csv)
• Scene data (*.scn)
• Scene group data (*.sgp)
• System data (*.ini)
• System settings + Scene group 0 data (*.bkd)
• Operation log (*.log)
3 Select the save destination folder.
To save the file by copying it to the external memory of the FH vision sensor, select [Sensor].
To save the file to the computer, select [Computer].
If you wish to delete the original file after saving, select the [Delete original data after save]
check box.
4 Save the file.
Click the [Save file] button to save the file.
The selected file is copied to the specified folder.
To Next Page
