Omron fh series Operation Manual

9 Limitations
9 - 2
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
9-1 Limitations
The FH tools have the following limitations.
List of the processing units supported in Sysmac Studio
Condition Limitation
Registration of multiple FH
series vision sensors to a
project
Eight FH vision sensors can be registered to one project.
Editing of processing units
Limitations apply to editing processing units in Sysmac Studio. Refer to the fol-
lowing table.
ż: Supported, x: Not supported
Processing Unit Registration Editing
Camera Image Input ż x
Camera Image Input FH żż
Camera Image Input HDR żż
Camera Image Input HDR Lite żż
Camera Switching żż
Measurement Image Switching żż
Position Compensation żż
Filtering żż
Background Suppression żż
Brightness Correct Filter ż
ż
*1
Advanced Filter żż
Image Subtraction ż
ż
*1
Color Gray Filter żż
Extract Color Filter żż
Anti Color Shading żż
Stripes Removal Filter II żż
Polar Transformation żż
Trapezoidal Correction żż
Panorama ż
ż
*1
Machine Simulator żż
Search żż
Flexible Search żż
Sensitive Search ż
ż
*1
EC Circle Search żż
ECM Search żż
Ec Corner żż
Ec Cross żż
Shape Search II żż
Shape Search III żż
Classification ż
ż
*1
Edge Position żż
Edge Pitch ż
ż
*1
Scan Edge Position żż
Scan Edge Width ż
ż
*1
Circular Scan Edge Position żż
Circular Scan Edge Width ż
ż
*1

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
