2 Basic Operations
Vision System FH Series Operation Manual for Sysmac Studio (Z343)
2-8 Precautions on Synchronization
through an NJ/NX-series Controller
2
2-8-3 Transferring Data from the Sysmac Studio
1 Procedures for saving the settings data for the FH sensor controller that is in the Sysmac Studio
(Sysmac Studio to external memory)
Save the data in the Sysmac Studio to the external memory. Then use the external memory to
transfer the data to the FH sensor controller. Refer to 2-4-4 Multiview Explorer on page 2-10.
Save following four types of the settings data individually.
(1) System + Scene group 0 data
Refer to 8-3 Using the File Save Tool on page 8-4.
(2) Data for scene groups 1 to 31
Refer to 8-3 Using the File Save Tool on page 8-4.
(3) Communications command macro data
Refer to 8-1 Using the Command Customize Setting Tool on page 8-2.
(4) Security settings data
Refer to 8-7 Using the Security Setting Tool on page 8-11.
Precautions for Correct Use
If the FH sensor controller is in the Multi-line Random-trigger Mode, the settings data for the FH
sensor controller must be saved for each individual line.
2 Procedures for transferring the data from the Sysmac Studio to the NJ/NX-series Controller
(Sysmac Studio to NJ/NX-series Controller)
Establish an online connection with the NJ/NX-series Controller to transfer the data from the
Sysmac Studio to the NJ/NX-series Controller. Refer to Sysmac Studio Version 1 Operation
Manual (Cat. No. W504-E1-08 or later).
(1) Establish an online connection between the NJ/NX-series Controller and the computer that
runs the Sysmac Studio.
(2) Select [Synchronize] from the [Controller] Menu.
(3) Select [Transfer to Sensor].
3 Procedures for transferring the data from the external memory to the FH sensor controller
(external memory to FH sensor controller)
Use the external memory that holds the settings data to load the data to the FH sensor control-
ler. Refer to 2-8-2 Saving and Loading the Settings Data for the FH Sensor Controller on page
2-41.
