Approx. 150 to 175
*
1
120
Unit: (mm)
*1. This is the dimension from the back of the Unit to the communications cables.
Approx. 150 mm: When MPS588-C connector is used
Approx. 175 mm: When XS6G-T421-1 connector is used
Precautions for Safe Use
Do not pull on the cables or bend the cables beyond their natural limit.
Doing so may break the cables.
5 Installation and Wiring
5-35
NX-series NX502 CPU Unit Hardware User's Manual (W629)
5-3 Mounting and Removing Units
5
5-3-14 Assembled Appearance and Dimensions
