4-13
4-2 Wiring
4
System Design
îš„ Connector-Terminal Block Conversion Units and Cables
These Conversion Units and Cables are used for connecting to Controllers for which no specific
cable is available. The Cables and Connector-Terminal Block Unit convert the Servo Drive's control
I/O Connector (CN1) signals to a terminal block.
îš„ General-purpose Control Cables (CN1)
A General-purpose Control Cable is used to prepare a cable by yourself to connect to the Servo
Drive’s Control I/O Connector (CN1).
Name Model Comments
Connector-Terminal
Block Conversion
Unit
XW2B-34G4 Terminal block with M3 screws
XW2B-34G5 Terminal block with M3.5 screws
XW2D-34G6 Terminal block with M3 screws
Connector-Terminal
Block Cable
XW2Z-@@@J-B28
This cable is used to connect a Connector-Termi-
nal Block Conversion Unit. The cable length is in-
dicated in the boxes of the model number (@@@).
There are two cable lengths: 1 m and 2 m. Model
number example for 1-m cable:
XW2Z-100J-B28
Name Model Comments
General-purpose
Control Cable
R7A-CPB@@@S
One end of the cable has loose wires.
The @@@ digits in the model number indicate the
cable length (1 m or 2 m).
Example model number for 1-m cable:
R7A-CPB001S
To Next Page
