Standard Models Appendix A
96
Name Model numberSpecifications
Analog I/O
Units
Analog Input
Unit
4 to 20 mA, 1 to 5/0 to 10 V (switchable); 4 inputs C200H-AD001
4 to 20 mA, 1 to 5/0 to 10/–10 to 10 V (switchable); 8 inputs C200H-AD002
Analog
Output Unit
4 to 20 mA, 1 to 5/0 to 10 V (switchable); 2 outputs C200H-DA001
4 to 20 mA, –10 to 10 V; 4 outputs C200H-DA002
Temperature Sensor Unit Thermocouple (K(CA) or J(IC)) (switchable); 4 inputs C200H-TS001
Thermocouple (K(CA) or L(Fe-CuNi)) (switchable); 4 inputs C200H-TS002
Platinum resistance thermometer (JPt) (switchable), DIN standards;
4 inputs
C200H-TS101
Platinum resistance thermometer (Pt) (switchable); 4 inputs C200H-TS102
Temperature Control Unit Thermocou-
Transistor output C200H-TC001
ple
Voltage output C200H-TC002
Current output C200H-TC003
Pt resis-
Transistor output C200H-TC101
ance
er-
mometer
Voltage output C200H-TC102
Current output C200H-TC103
Heat/Cool Temperature
Control Unit
Thermocou-
ple
Transistor output C200H-TV001
Voltage output C200H-TV002
Current output C200H-TV003
Pt resis-
Transistor output C200H-TV101
ance
er-
mometer
Voltage output C200H-TV102
Current output C200H-TV103
PID Control Unit Transistor output C200H-PID01
Voltage output C200H-PID02
Current output C200H-PID03
Position Control Unit 1 axis Pulse output; speeds: 1 to 99,990 pps C200H-NC111
1 axis Directly connectable to servomotor driver; compatible
with line driver; speeds: 1 to 250,000 pps
C200H-NC112
2 axis 1 to 250000. pps. 53 pts per axis C200H-NC211
Cam Positioner Unit Detects angles of rotation by means of a resolver and provides ON and
OFF outputs at specified angles. A maximum of 48 cam outputs (16 ex-
ternal outputs and 32 internal outputs) maximum are available.
C200H-CP114
High-speed Counter Unit 1 axis Pulse input; counting speed: 50 kcps;
5 VDC/12 VDC/24 VDC
C200H-CT001-V1
1 axis Pulse input; counting speed: 75 kcps;
RS-422 line driver
C200H-CT002
ASCII Unit EEPROM C200H-ASC02
Connecting
Cable
For connecting the ASCII Unit to the FIT10 (9P/25P)
Cable length: 2 m
CV500-CN228
I/D Sensor Unit Local application, electromagnetic coupling C200H-IDS01-V1
Remote application, microwave transmissions C200H-IDS21
Read/Write
Electromagnetic type V600-H series
Head
Microwave type V620-H series
Data Carrier
SRAM type for V600-H series.
V600-DjjRjj
(see note)
EEPROM type for V600-H series.
V600-DjjPjj
Voice Unit 60 messages max.; message length: 32, 48, or 64 s (switchable) C200H-OV001
Connecting
Cable
RS-232C C200H-CN224
To Next Page
