Appendix AStandard Models
97
Name Model numberSpecifications
Fuzzy Logic Unit Up to 8 inputs and 4 outputs. (I/O to and from specified data area words) C200H-FZ001
Fuzzy
Support
Software
Available on either 3.5” or 5.25” floppy disks.
C500-SU981-E
Note For Read/Write Head and Data Carrier combinations, refer to the V600 FA ID System R/W Heads and EE-
PROM Data Carriers Operation Manual and Supplement or V600 FA ID System R/W Heads and SRAM
Data Carriers Operation Manual and Supplement.
C200H Link Units
Name Specifications Model number
Host Link Unit Rack-mounting C200H only APF/PCF C200H-LK101-PV1
RS-422 C200H-LK202-V1
RS-232C C200H-LK201-V1
PC Link Unit Multilevel RS-485 C200H-LK401
Remote I/O Master Unit Up to two per PC; connectable to up to 5
Slaves per PC total
APF/PCF C200H-RM001-PV1
Wired C200H-RM201
SYSMAC LINK Unit/SYSMAC NET Link Units
The SYSMAC LINK Units and SYSMAC NET Link Unit can only be used with the C200HS-CPU31-E and C200HS-
CPU33-E CPUs.
Name Specifications Model number
SYSMAC LINK Unit
Wired via coaxial cable.
Bus Connection Unit required separately. One
C1000H-CE001 F Adapter included.
Data link
capacity:
918 words
C200HW-SLK23
p
Data link
capacity:
2,966 words
C200HW-SLK24
Wired via optical fiber cable.
Bus Connection Unit required separately. An
Optical Fiber Cable Bracket must be used to
ttilbl tdtth
Data link
capacity:
918 words
C200HW-SLK13
p
support an optical cable connected to the
SYSMAC LINK Unit.
Data link
capacity:
2,966 words
C200HW-SLK14
Terminator One required for each node at ends of System C1000H-TER01
Attachment Stirrup Provided with SYSMAC LINK Unit C200H-TL001
F Adapter --- C1000H-CE001
F Adapter Cover --- C1000H-COV01
Communications
Cbl
Coaxial cables Manufactured by Hitachi ECXF5C-2V
Cable
Manufactured by Fujigura 5C-2V
Auxiliary Power Sup-
ply Unit
Supplies backup power to either one or two SYSMAC LINK
Units. One C200H-CN111 Power Connecting Cable included.
C200H-APS03
SYSMAC NET Link Unit Bus Connection Unit required separately. An Optical Fiber
Cable Bracket must be used to support an optical cable con-
nected to the SYSMAC NET Link Unit.
C200HS-SNT32
Power Supply Adapt- Required when supplying power from Central
PSl
For 1 Unit C200H-APS01
pp y p
er
qppygp
Power Supply
For 2 Units C200H-APS02
Power Cable
Connects Power Supply Adapter and SYS-
MAC NET Li k U i
For 1 Unit C200H-CN111
pp y p
MAC NET Link Unit
For 2 Units C200H-CN211
