Appendix AStandard Models
99
Link Adapters
Name Specifications Model number
Link Adapter
3 RS-422 connectors 3G2A9-AL001
3 optical connectors (APF/PCF) 3G2A9-AL002-PE
3 optical connectors (PCF) 3G2A9-AL002-E
1 connector each for APF/PCF, RS-422, and RS-232C 3G2A9-AL004-PE
1 connector each for PCF, RS-422, and RS-232C 3G2A9-AL004-E
1 connector each for APF/PCF and APF 3G2A9-AL005-PE
1 connector each for PCF and AGF 3G2A9-AL005-E
1 connector for APF/PCF; 2 for AGF 3G2A9-AL006-PE
O/E converter; 1 connector for RS-485, 1 connector each for APF/PCF B500-AL007-PE
Used for on-line removal of SYSMAC NET Link Units from the SYSMAC
NET Link System, SYSMAC NET Optical Link Adapter 3 connectors for
APF/PCF.
B700-AL001
SYSMAC BUS/SYSMAC WAY Optical Fiber Products
Plastic Clad Optical Fiber Cable/All Plastic Optical Fiber Cable
Name Specifications Model number
Plastic Clad Optical Fiber Cable
(indoor)
0.1 m, w/connectors
Ambient temp:
10° to 70°C
3G5A2-OF011
(indoor)
1 m, w/connectors
–10° to 70°C
3G5A2-OF101
2 m, w/connectors 3G5A2-OF201
3 m, w/connectors 3G5A2-OF301
5 m, w/connectors 3G5A2-OF501
10 m, w/connectors 3G5A2-OF111
20 m, w/connectors 3G5A2-OF211
30 m, w/connectors 3G5A2-OF311
40 m, w/connectors 3G5A2-OF411
50 m, w/connectors 3G5A2-OF511
Cable only; order desired length between 1
and 200 m in increments of 1 m.
B500-OF002
All Plastic Optical Fiber Cable Cable only; order desired length in 5 m increments between
5 and 100 m, or in increments of 200 m or 500 m.
B500-PF002
Optical Connectors A Two optical connectors (brown) for APF (10 m max.) 3G5A2-CO001
Optical Connectors B Two optical connectors (black) for APF (8 to 20 m) 3G5A2-CO002
All Plastic Optical Fiber Cable Set 1-m cable with an Optical Connector A connected to each
end
3G5A2-PF101
Optical Fiber Processing Kit Accessory: 125-mm nipper (Muromoto Tekko’s 550M) for
APF
3G2A9-TL101
