Omron SYSMAC C200HS Installation Guide

Standard Models Appendix A
100
H-PCF
Name Specifications Model number
Optical Fiber Cable
SYSMAC BUS SYSMAC WAY
10 m, black Two-core cable S3200-HCCB101
SYSMAC BUS, SYSMAC WAY
50 m, black
S3200-HCCB501
100 m, black S3200-HCCB102
500 m, black S3200-HCCB502
1000 m, black S3200-HCCB103
10 m, orange S3200-HCCO101
50 m, orange S3200-HCCO501
100 m, orange S3200-HCCO102
500 m, orange S3200-HCCO502
1000 m, orange S3200-HCCO103
10 m, black Two-core cable S3200-HBCB101
50 m, black S3200-HBCB501
100 m, black S3200-HBCB102
500 m, black S3200-HBCB502
1000 m, black S3200-HBCB103
Optical Fiber Cable Connector SYSMAC BUS:
C200H-RM001-PV1
C200H-RT001/RT002-P
C500-RM001-(P)V1
C500-RT001/RT002-(P)V1
B500-jjj(-P)
Half-lock connector
for Remote I/O Mas-
ter, Remote I/O
Slave, Host Link
Unit, and Link
Adapter
S3200-COCH82
Note 1. Optical fiber cables must be prepared and connected by specialists.
2. If the user prepares and connects optical fiber cables, the user must take a seminar held under the aus-
pices of Sumitomo Electric Industries, Ltd. and obtain a proper certificate.
3. The Optical Power Tester, Head Unit, Master Fiber Set, and Optical Fiber Assembling Tool are required
to connect optical fiber cables.
Optical Fiber Assembling Tool
Name Specifications Model number
Optical Fiber Assembling Tool Used to connect H-PCF and crimp-cut connectors for opti-
cal transmission systems such as the SYSMAC C- and
CV-series SYSMAC BUS, SYSMAC LINK and SYSMAC
NET.
S3200-CAK1062
Note 1. Optical fiber cables must be prepared and connected by specialists.
2. The Optical Power Tester, Head Unit, Master Fiber set, and Optical Fiber Assembling Tool are required
to connect optical fiber cables.
Optical Power Tester
Name Specifications Head Unit Model number
Optical Power Tester (see note)
(provided with a connector adapter,
light source unit, small single-head
plug, hard case, and AC adapter)
SYSMAC BUS:
C200H-RM001-PV1
C200H-RT001/RT002-P
C500-RM001-(P)V1
C500-RT001/RT002-(P)V1
S3200-CAT2822
(provided with the
Tester)
S3200-CAT2820
Note: There is no difference between the light source unit and connector adapter for the Head Unit and those for
the Optical Power Tester.
