Omron SYSMAC C200HS Installation Guide

Appendix BSpecifications
198
Fujitsu’s Connector is Used
G79-jC Connecting Cable is Used
118
118
145
Approx. 163
Backplane Backplane
G79-jC
Connecting
Cable
Connecting
cable
Dimensions with Unit Mounted
Interrupt Input Unit
The dimensions shown below are for the Interrupt Input Unit classified as Special I/O Units.
Backplane
x
x
x
x
130
35
101
118
Standard B7A Interface Unit
The dimensions shown below are for the B7A Interface Unit classified as Special I/O Units.
130
35
101
118
Backplane

Omron SYSMAC C200HS Specifications

General

Brand	Omron
Model	SYSMAC C200HS
Category	Controller
Language	English
