Appendix B
Specifications
200
Mounting Dimensions
A
±
0.2
B
±
0.2
11
8
±
0.2
80 to 120
11
8
±
0.2
W
Four (five), M4
130
68 to 108
130
Backplane
Backplane
Four (five), M4
Model
A
±
0.2
B
±
0.2
W
C200H-BC031-V2
246 mm
---
260 mm
C200H-BC051-V2
316 mm
---
330 mm
C200H-BC081-V2
421 mm
---
435 mm
C200H-BC101-V2
491 mm
270.5 mm
505 mm
Panel Mounting of C200H-PRO27 Programming Console
Bracket
T
wo screws
Panel thickness (t = 1.0 to 3.2)
213
215
