165
Appendix B
Programming Instructions
A PC instruction is input either by inputting the corresponding Programming Console key(s) (e.g., LD, AND, OR, NOT) or by using func-
tion codes. To input an instruction via its function code, press FUN, the function code, and then WRITE.
Function code
Name Mnemonic Page
–– AND AND 48
–– AND Load AND LD 49
–– AND NOT AND NOT 48
–– Counter CNT 64
–– Load LD 48
–– Load NOT LD NOT 48
–– OR OR 48
–– OR NOT OR NOT 48
–– OR Load OR LD 49
–– Output OUT 49
–– Output NOT OUT NOT 49
–– Timer TIM 57
00 No Operation NOP 56
01 End END 56
02 Interlock IL 53
03 Interlock Clear ILC 53
04 Jump JMP 55
05 Jump End JME 55
10 Shift Register SFT 78
11 Keep KEEP 51
12 Reversible Counter CNTR 67
13 Differentiate Up DIFU 50
14 Differentiate Down DIFD 50
15 High–speed Timer TIMH 61
16 Word Shift WSFT 80
20 Compare CMP 82
21 Move MOV 81
22 Move NOT MVN 82
23 BCD to Binary BIN 84
24 Binary to BCD BCD 85
30 BCD Add ADD 90
31 BCD Subtract SUB 92
40 Set Carry STC 93
41 Clear Carry CLC 93
76 4 to 16 Decoder MLPX 85
77 16 to 4 Encoder DMPX 87
98 High–speed Counter HDM 68
